Product Description:
One of the key features of Semi Hermetic Compressors is the number
of cylinders they come with. These compressors are available in 2,
4, or 6 cylinder configurations, which means that they can be
tailored to meet the specific needs of your application. This
allows you to achieve the right balance of power and efficiency,
ensuring that your refrigeration system is operating at peak
performance.
Another important feature of Semi Hermetic Compressors is their
speed. These compressors are available in both variable and fixed
speed options, which means that you can choose the right compressor
for your application based on your specific power needs. Variable
speed compressors are ideal for applications where energy
efficiency is a top priority, while fixed speed compressors are
better suited for applications where a consistent level of power is
required.
Motor protection is also an important consideration when selecting
a Semi Hermetic Compressor. These compressors are designed with
thermal overload protection, which helps to prevent damage to the
motor in the event of overheating. This ensures that your
compressor will continue to operate reliably and efficiently, even
in the most demanding environments.
Semi Hermetic Compressors are classified as reciprocating
compressors, which means that they use a piston and cylinder to
compress refrigerant gas. This design allows for efficient
operation and precise control over the refrigeration process,
making these compressors a popular choice for a wide range of
refrigeration applications.
Finally, it is important to consider the operating temperature
range of Semi Hermetic Compressors. These compressors are designed
to operate in temperatures ranging from -40°C to +10°C, which means
that they can be used in a variety of environments and settings.
This makes them an ideal choice for applications where temperature
control is critical.
Compressor
type | Nominal
motor
power
HP/KW | Dispiacement(50Hz)m³/h | Number of
Cylinder
xDiameter
xStroke(mm) | Aspirator,exhaust
valve take-over | Oil
injection volume(L) | Power supply
V/Ø/Hz | Electrical parameter | Crankcase
Heater
(220) W | Oil
supply method | Weight
(including
freezing oil)Kg |
Low
Pressure | High
Pressure | DL | SL | Max
operating
current(A) | Starting
current/Motor
locked current(A |
|
|
| 6H-25.2 | 25/18.5 | | 110.5 | 6xФ70x55 | Ø35
1-3/8" | Ø54
2-1/8" | 4.75 | 380~
420YY
/3/50
440~
480YY
/3/60 | 45 | 147/262 | 140 | Forced-
lubrication | 237 |
| 6H-35.2 | 35/25.5 | | 110.5 | 6xФ70x55 | Ø35
1-3/8" | Ø54
2-1/8" | 4.75 | 62 | 116/193 | 140 | 248 |
| 6G-30.2 | 30/22 | | 126.8 | 6xФ75x55 | Ø35
1-3/8" | Ø54
2-1/8 | 4.75 | 53 | 135/220 | 140 | 241 |
| 6G-40.2 | 40/30 | | 126.8 | 6xФ75x55 | Ø35
1-3/8" | Ø54
2-1/8 | 4.75 | 78 | 180/323 | 140 | 247 |
| 6F-40.2 | 40/30 | | 151.6 | 6xФ82x55 | Ø42
1-5/8" | Ø54
2-1/8 | 4.75 | 78 | 180/323 | 140 | 243 |
| 6F-50.2 | 50/37 | | 151.6 | 6xФ82x55 | Ø42
1-5/8" | Ø54
2-1/8 | 4.75 | 92 | 226/404 | 140 | 248 |
Applications:
The DM-YSJ-P Semi-hermetic Reciprocating Compressors are suitable
for use in a wide range of Compressor Systems, including those used
in Cold Rooms, refrigeration plants, and air conditioning units.
They are designed to provide high-efficiency performance with
minimal noise, making them a popular choice for many commercial and
industrial applications.
The DM-YSJ-P Semi-hermetic Reciprocating Compressors are compatible
with both Mineral and Synthetic Oil types, allowing for greater
versatility in their use. They are available in both Single and
Three-phase power supply options, making them ideal for use in a
variety of different environments.
The DM-YSJ-P Semi-hermetic Reciprocating Compressors are available
in a range of Displacement sizes, ranging from 2 to 100 M3/h. This
makes them suitable for use in a variety of applications, from
small refrigeration units to large-scale industrial systems. They
are designed to operate at high-efficiency levels while maintaining
a low energy consumption, making them an ideal choice for those
looking to reduce their energy costs.
In summary, the DM-YSJ-P Semi-hermetic Reciprocating Compressors
are a versatile and efficient option for those looking for a
reliable piston compressor. With a range of Displacement sizes and
compatibility with both Mineral and Synthetic Oil types, they are
suitable for a wide range of applications. Their high-energy
efficiency and low-noise operation make them an ideal choice for
use in Compressor Systems, Cold Room Compressor, and various other
refrigeration and air conditioning units.
Packing and Shipping:
Product Packaging:
- The semi hermetic compressors are carefully packed in sturdy
cardboard boxes.
- The boxes are sealed with high-quality tape to prevent any damage
during transportation.
- Each compressor is protected with foam padding to ensure that it
does not get scratched or dented.
- The packaging also includes a user manual and installation guide.
Shipping:
- The semi hermetic compressors are shipped via a reputable courier
service that provides tracking information.
- Shipping costs are calculated based on the size and weight of the
compressors as well as the destination.
- Customers can expect their order to be shipped within 2-3 business
days after payment is received.
- Delivery times may vary depending on the destination and courier
service used.
FAQ:
Q: What is the brand name of the Semi Hermetic Compressors product?
A: The brand name of the Semi Hermetic Compressors product is DM.
Q: What is the model number of the Semi Hermetic Compressors
product?
A: The model number of the Semi Hermetic Compressors product is
DM-YSJ-P.
Q: Where is the Semi Hermetic Compressors product manufactured?
A: The Semi Hermetic Compressors product is manufactured in China.
Q: What type of refrigerant does the Semi Hermetic Compressors
product use?
A: The Semi Hermetic Compressors product is compatible with a
variety of refrigerants, including R22, R404a, R134a, and more.
Q: What are the applications for the Semi Hermetic Compressors
product?
A: The Semi Hermetic Compressors product is widely used in
commercial refrigeration, air conditioning, and other related
industries.
