Product Description:
With a voltage rating of 380V/220V and a frequency of 50Hz/60Hz,
this compressor is perfect for a wide range of industrial and
commercial applications. Whether you need to power up compressor
tubes, inflation compressors, or cold storage compressors, the
Damai Compressor is up to the task.
This compressor is built to last, with durable components and a
compact design that can withstand the most demanding environments.
The dimensions of the compressor are 50x30x40cm, making it easy to
transport and store, while still providing plenty of power and
performance.
Technical Parameters:
Compressor Specifications
The following table details the specifications of the compressors.
| Model NO. | Cooling Capacity (rating point 7.2) | nominal hp | Displ. cc/rev | nom current | Weight |
| FLa | (Kg) |
| ZR22K3PFJ522 | 5240 | 1.83 | 30.7 | 9.6 | 26 |
| ZR28K3PFJ522 | 6970 | 2.33 | 39.2 | 12.9 | 27.3 |
| ZR28K3EPFJ522 | 6970 | 2.33 | 39.2 | 12.9 | 27.3 |
| ZR34K3PFJ522 | 8260 | 2.83 | 46.1 | 13.6 | 29.5 |
| ZR34K3EPFJ522 | 8260 | 2.83 | 46.1 | 13.6 | 29.5 |
| ZR36K3PFJ522 | 8850 | 3 | 49.5 | 16.4 | 29.5 |
| ZR40K3PFJ522 | 9620 | 3.33 | 54.19 | 17.1 | 32 |
| ZR42K3PFJ522 | 10140 | 3.5 | 56.8 | 17.1 | 30 |
| ZR47K3PFJ522 | 11500 | 3.9 | 64.1 | 19.3 | 32.6 |
| ZR68KCPFJ522 | 16800 | 5.75 | 93 | 28.2 | 43.5 |
| ZR28K3TFD522 | 6970 | 2.33 | 39.2 | 5 | 26 |
| ZR28K3ETFD522 | 6970 | 2.33 | 39.2 | 5 | 26 |
| ZR36K3TFD522 | 8850 | 3 | 49.5 | 5.7 | 29.5 |
| ZR40K3TFD522 | 9260 | 3.33 | 51.2 | 6.4 | 32 |
| ZR47KCTFD522 | 11400 | 3.9 | 63.2 | 7.2 | 32.6 |
| ZR47KCETFD522 | 11400 | 3.9 | 63.2 | 7.2 | 32.6 |
| ZR48KCTFD522 | 11500 | 4.1 | 67.2 | 7.5 | 38 |
| ZR48KCETFD522 | 11500 | 4.1 | 67.2 | 7.5 | 38 |
| ZR54KCTFD522 | 13000 | 4.5 | 73.2 | 8.2 | 35.5 |
| ZR57KCTFD522 | 13660 | 4.75 | 76.9 | 8.2 | 36 |
| ZR57KCETFD522 | 13660 | 4.75 | 76 | 8.2 | 36 |
| ZR61KCTFD522 | 14700 | 5 | 82.4 | 10 | 35.9 |
| ZR61KCETFD522 | 14700 | 5 | 82.4 | 10 | 35.9 |
| ZR68KCTFD522 | 16500 | 5.75 | 93 | 10 | 38.2 |
| ZR72KCTFD522 | 17800 | 6 | 98 | 10 | 38.2 |
| ZR72KCETFD522 | 17800 | 6 | 98 | 10 | 38.2 |
| ZR81KCTFD522 | 19800 | 6.75 | 110.6 | 12 | 40 |
| ZR81KCETFD522 | 19800 | 6.75 | 110.6 | 12 | 40 |
| ZR94KCTFD522 | 23000 | 8 | 127.2 | 16.2 | 59 |
| ZR94KCTFD523 | 23200 | 8 | 127.2 | 16.2 | 58.2 |
| ZR94KCETFD523 | 23200 | 8 | 127.2 | 16.2 | 58.2 |
| ZR108KCTFD522 | 26670 | 9 | 147.5 | 17.3 | 64 |
| ZR108KCETFD523 | 26670 | 9 | 147.5 | 17.3 | 64 |
| ZR108KCTFD523 | 26900 | 9 | 144.5 | 17.3 | 62.7 |
| ZR125KCTFD522 | 30660 | 10 | 171.4 | 19.2 | 64 |
| ZR125KCETFD523 | 31000 | 10 | 165.6 | 19.2 | 62.7 |
| ZR125KCTFD523 | 31000 | 10 | 165.6 | 19.2 | 62.7 |
Applications:
The Damai Compressor is perfect for a variety of applications,
including but not limited to:
- Compressor Tubes: This compressor is ideal for powering compressor
tubes, which are used in various industries, including HVAC,
refrigeration, and pneumatic systems. The DM-YSJ model is capable
of generating high-pressure air, making it perfect for powering
compressor tubes.
- Piston Compressor: The Damai Compressor is a piston compressor,
which means it uses a series of pistons to compress air. This type
of compressor is commonly used in automotive repair shops, small
manufacturing plants, and other industrial settings.
- Air Compressor: This product can also be used as an air compressor,
which is used to power pneumatic tools such as nail guns, impact
wrenches, and paint sprayers. The DM-YSJ model has a voltage of
380V/220V, making it suitable for a wide range of applications.
In addition to its versatility, the Damai Compressor also comes
with a 1-year warranty, giving you peace of mind in case anything
goes wrong. Whether you're a professional mechanic, HVAC
technician, or just someone who likes to work on DIY projects at
home, the Damai Compressor is a reliable and efficient tool that
will help you get the job done.
Packing and Shipping:
Product Packaging:
The Damai Compressor product will be carefully packaged in a sturdy
cardboard box with ample padding to ensure it arrives in excellent
condition. The package will include the compressor unit, power
cord, and user manual.
Shipping:
The Damai Compressor product will be shipped via standard ground
shipping within the United States. Shipping times may vary
depending on the destination, but customers can expect their
package to arrive within 5-7 business days from the date of
shipment. International shipping is not currently available for
this product.
FAQ:
Q: What is the brand name of the compressor?
A: The brand name of the compressor is Damai.
Q: What is the model number of the compressor?
A: The model number of the compressor is DM-YSJ.
Q: Where is the Damai compressor manufactured?
A: The Damai compressor is manufactured in China.
Q: What is the power rating of the Damai compressor?
A: The power rating of the Damai compressor is 1.5 horsepower.
Q: What is the maximum pressure that the Damai compressor can
deliver?
A: The Damai compressor can deliver a maximum pressure of 8 bar or
115 psi.
