H 2-4 Fans Air Cooler Condenser With Smooth Copper Tube Material
Product Description:
The H condenser is installed on the refrigeration unit in
conjunction with the compressor and is suitable for different cold
storage temperatures
Features:
The product can tolerate environments with temperatures ranging
from 0 to 10°C and -15 to -25°C. This means that it is designed to
function optimally in areas with moderate to extremely low
temperatures.
Horsepower:
Our product is built with a range of horsepower options, from 3HP
to 34HP. This gives customers the flexibility to choose the right
level of power for their specific needs.
Voltage:
Our product is designed to work with a variety of voltage options,
including 380V/3P/50Hz, 220V/3P/60Hz, and 380V/3P/60Hz. This allows
us to cater to customers in different regions and provide them with
the flexibility they need to use our product in their specific
setting.
Technical Parameters:
Advantages of Semi-hermetic Compressor Condensing Unit for Cold
Room
- Compact structure
- Complete protective devices
- Increased condenser to ensure good heat dissipation
- Keep good cooling effect for a long time
- Save 30% electricity bill
- Low noise
- Using brand accessories and parts
When it comes to cold room refrigeration systems, the choice of
compressor condensing unit can make all the difference. One option
to consider is a semi-hermetic compressor condensing unit, which
offers a variety of advantages over other types of units. One key
advantage is the compact structure of the semi-hermetic compressor
condensing unit. This allows for easier handling and installation,
as well as efficient use of space within the cold room. Another
benefit is the complete protective devices included with the unit.
These devices help to ensure the safety and longevity of the
compressor and other components, preventing costly breakdowns and
repairs. The semi-hermetic compressor condensing unit also features
an increased condenser, which enables better heat dissipation. This
leads to improved cooling performance and a longer lifespan for the
unit overall. In addition to these benefits, the semi-hermetic
compressor condensing unit can save up to 30% on electricity bills
compared to other types of units. It also operates with low noise,
making it a good choice for a variety of environments. Finally, the
unit is designed to use brand accessories and parts, ensuring
compatibility and reliable performance over time. All of these
features make the semi-hermetic compressor condensing unit a strong
choice for anyone in need of a cold room refrigeration system.
| Model | Heat exchange capacity
(kW) | Surface(m2) | Copper tube arrangement | Fan | Inletø (mm) | Outletø (mm) | Weight(kg) |
| Qty | Power(W) | Air flow
(m³/h) | Fan ø(mm) | Voltage (V) |
| FNHM-002 | 0.6 | 2 | 2×4 | 1 | 33 | 500 | 200 | 220 | 10 | 10 | 4 |
| FNHM-003 | 0.8 | 3 | 3×4 | 1 | 33 | 500 | 200 | 220 | 10 | 10 | 4.3 |
| FNHM-003/A | 1.0 | 3.4 | 3×4.5 | 1 | 33 | 800 | 200 | 220 | 10 | 10 | 4.5 |
| FNHM-004 | 1.2 | 4 | 3×5 | 1 | 60 | 800 | 250 | 220 | 10 | 10 | 6 |
| FNHM-005 | 1.5 | 5.2 | 3×6 | 1 | 75 | 1250 | 300 | 220 | 10 | 10 | 8 |
| FNHM-007 | 2.0 | 7 | 4×6 | 1 | 75 | 1250 | 300 | 220 | 10 | 10 | 10.2 |
| FNHM-012 | 3.5 | 12 | 4×8 | 1 | 90 | 1800 | 350 | 380 | 19 | 16 | 13.8 |
| FNHM-015 | 4.4 | 15 | 4×9 | 1 | 90 | 1800 | 350 | 380 | 19 | 16 | 16.5 |
| FNHM-018 | 5.2 | 18 | 4×10 | 1 | 120 | 3000 | 400 | 380 | 19 | 16 | 22 |
| FNHM-022 | 6.4 | 22 | 5×10 | 1 | 120 | 3000 | 400 | 380 | 19 | 16 | 24 |
| FNHM-022/A | 6.4 | 22 | 4×8 | 2 | 2×90 | 2×1800 | 350 | 380 | 19 | 16 | 26 |
| FNHM-028 | 8.1 | 28 | 4×9 | 2 | 2×90 | 2×1800 | 350 | 380 | 19 | 16 | 29 |
| FNHM-033 | 9.6 | 33 | 4×10 | 2 | 2×120 | 2×3000 | 400 | 380 | 19 | 16 | 36 |
| FNHM-041 | 13.0 | 41 | 5×10 | 2 | 2×120 | 2×3000 | 400 | 380 | 19 | 16 | 40 |
| FNHM-049 | 15.0 | 49 | 5×12 | 2 | 2×120 | 2×3000 | 400 | 380 | 19 | 16 | 50 |
| FNHM-055 | 16.5 | 55 | 4×14 | 2 | 2×120 | 2×3000 | 400 | 380 | 22 | 19 | 54 |
| FNHM-060 | 18.0 | 60 | 5×12 | 2 | 2×120 | 2×3000 | 400 | 380 | 22 | 19 | 58 |
| FNHM-062 | 18.5 | 62 | 4×18 | 4 | 4×120 | 4×1800 | 350 | 380 | 25 | 22 | 65 |
| FNHM-070 | 20.0 | 70 | 4×18 | 4 | 4×120 | 4×1800 | 350 | 380 | 25 | 22 | 72 |
| FNHM-072 | 20.6 | 72 | 5×15 | 2 | 2×250 | 2×4500 | 450 | 380 | 25 | 19 | 68 |
| FNHM-080 | 22.3 | 80 | 4×20 | 4 | 4×120 | 4×3000 | 400 | 380 | 25 | 22 | 81 |
| FNHM-080/A | 22.3 | 80 | 5×16 | 2 | 2×450 | 2×6000 | 500 | 380 | 25 | 22 | 81 |
| FNHM-100 | 28.6 | 100 | 5×20 | 4 | 4×120 | 4×3000 | 400 | 380 | 25 | 22 | 90 |
| FNHM-120 | 34.8 | 120 | 5×24 | 4 | 4×120 | 4×3000 | 400 | 380 | 32 | 25 | 105 |
| FNHM-140 | 40.6 | 140 | 6×24 | 4 | 4×250 | 4×4500 | 450 | 380 | 32 | 25 | 128 |
| FNHM-150 | 43.5 | 150 | 5×24 | 4 | 4×450 | 4×6000 | 500 | 380 | 32 | 25 | 135 |
| FNHM-180 | 52.2 | 180 | 6×24 | 4 | 4×450 | 4×6000 | 500 | 380 | 32 | 25 | 170 |
| FNHM-220 | 64.9 | 220 | 6×24 | 6 | 6×250 | 6×4500 | 450 | 380 | 32 | 32 | 210 |
| FNHM-270 | 80.0 | 270 | 6×24 | 6 | 6×450 | 6×6000 | 500 | 380 | 35 | 35 | 255 |
Applications:
A cold storage refrigeration system is an essential component of
many businesses, particularly those in the food and beverage
industry. This system is responsible for maintaining a consistent
and safe temperature for stored goods, such as perishable foods,
pharmaceuticals, and chemicals. Without a reliable refrigeration
system, products can spoil, and businesses can suffer significant
financial losses.
Cold storage refrigeration systems typically consist of several
working components, including compressors, condensers, evaporators,
and refrigerants. Compressors compress refrigerant gases,
increasing their temperature and pressure. The condenser then cools
these gases, causing them to liquefy and release heat. The
refrigerant then flows through the evaporator, where it absorbs
heat and cools the storage space.
The proper installation and maintenance of a cold storage
refrigeration system is crucial for ensuring its optimal
performance and longevity. Routine inspections, cleaning, and
repairs can help prevent breakdowns and costly repairs.
Additionally, upgrading to more energy-efficient components can
help reduce operating costs and improve sustainability.
Customization:
Support and Services:
The Air Cooler Condenser product comes with a comprehensive
technical support and services package to ensure that our customers
have a smooth and hassle-free experience with our product. Our
technical support team is available to answer any questions or
concerns you may have regarding installation, operation, and
maintenance of the product. We also offer repair and maintenance
services to ensure that your product remains in good working
condition throughout its lifespan. Our team of certified
technicians is trained to handle any issues that may arise with the
product and provide prompt and efficient solutions. In addition, we
offer warranty services to provide our customers with added peace
of mind. Our goal is to provide our customers with the highest
level of support and services possible to ensure their complete
satisfaction with our product.
Packing and Shipping:
Product Packaging:
- Single unit air cooler condenser
- Protective foam packaging
- User manual
Shipping:
- Ships within 1-2 business days
- Free standard shipping within the US
- International shipping available at an additional cost
- Tracking number provided
FAQ:
Q1: What certifications does the air cooler condenser have?
A1: The air cooler condenser has CE and ISO certifications.
Q2: What is the minimum order quantity for the air cooler
condenser?
A2: The minimum order quantity for the air cooler condenser is 1.
Q3: What is the price range for the air cooler condenser?
A3: The price range for the air cooler condenser is $200~$100000.
Q4: What are the packaging details for the air cooler condenser?
A4: The air cooler condenser is packaged in a wooden case.
Q5: What is the delivery time for the air cooler condenser?
A6: The delivery time for the air cooler condenser is 30 work days.
Q7: What are the payment terms for the air cooler condenser?
A7: The payment terms for the air cooler condenser are T/T and L/C.
