Refrigeration capacity of this series covers from 1.2KW to 114KW,
fitting with different refrigerant such as
R134a·R404A·R507A·R407C·R22.
Characteristics:
Scientific structure, high efficiency, uniform defrosting, saving
power and BW running cost.
Combined with silent model of axial fan, which provides powerful
air flow with long shot range, saving power and long life.
The airtightness between pipe and fin after expansion process is
perfect.
Combined with stainless electric heater, it has high insulation and
can defrost efficiently in shot time.
The heat exchange coil has passed airtightness test at air pressure
up to 2.6MPa.
With aluminum and painted stampboard, it can meet different needs.
Sphere of application
High temperature type:
(temp12~- 2ºC)fin space:4.5mm;
Medium temperature type:
(-2 ~- 10ºC) fin space:6.0mm;
Low temperature type:
(- 10~-31ºC)fn space:9.0mm;
→Tailor-made for customers
How to select right unit cooler model according to selected
compressor rating condition refrigerating capacity:
Choose the appropriate square number to match the size of the air
cooler. The fresh-keeping warehouse is matched with a normal square
number, and the height increases by one level. The low-temperature
warehouse is further increased by one level
Parameter table:
| Model | Nominal cooling capacity | Cooling area | Pitch of fins | Fan | Deforost electrothemal tube | Weight(kg) |
| Number | Diameter | Air volume | Wide pressure | Range | Fan power | Moter voltage | Coil(kw) | Water pond(kw) | Voltage(V) |
| DD-1.4/7 | 1400(1200) | 7 | 6.0 | 1 | ∅300 | 1700 | 98(10) | 8 | 90 | 380 | 0.9 | 0.4 | 220 | 27 |
| DD-2.35/12 | 2350(2000) | 12 | 6.0 | 2 | ∅300 | 2×1700 | 98(10) | 8 | 2×90 | 380 | 1.2 | 0.4 | 220 | 40 |
| DD-3.0/15 | 3000(2600) | 15 | 6.0 | 2 | ∅300 | 2×1700 | 98(10) | 8 | 2×90 | 380 | 1.35 | 0.45 | 220 | 46 |
| DD-4.0/22 | 4000(3450) | 21.5 | 6.0 | 3 | ∅300 | 3×1700 | 98(10) | 8 | 3×90 | 380 | 1.8 | 0.6 | 220 | 55 |
| DD-6.0/30 | 6000(5150) | 30 | 6.0 | 2 | ∅400 | 2×3000 | 118(120) | 12 | 2×216 | 380 | 2.6 | 1.3 | 220 | 70 |
| DD-8.0/40 | 8000(6900) | 40 | 6.0 | 2 | ∅400 | 2×3000 | 118(120) | 12 | 2×216 | 380 | 2.8 | 1.4 | 220 | 80 |
| DD-12.0/60 | 12000(10300) | 60 | 6.0 | 2 | ∅500 | 2×6000 | 167(17) | 15 | 2×550 | 380 | 6.0 | 1.5 | 220 | 115 |
| DD-15.9/80 | 15900(13700) | 80 | 6.0 | 2 | ∅500 | 2×6000 | 167(17) | 15 | 2×550 | 380 | 7.5 | 1.5 | 220 | 150 |
| DD-20.0/100 | 20000(17200) | 100 | 6.0 | 3 | ∅500 | 3×6000 | 167(17) | 15 | 3×550 | 380 | 9.5 | 1.9 | 220 | 170 |
| DD-24.0/120 | 24000(20650) | 120 | 6.0 | 3 | ∅500 | 3×6000 | 167(17) | 15 | 3×550 | 380 | 11.0 | 2.2 | 220 | 200 |
| DD-28.0/140 | 28000(24100) | 140 | 6.0 | 4 | ∅500 | 4×6000 | 167(17) | 15 | 4×550 | 380 | 12 | 2.4 | 220 | 240 |
| DD-32.1/160 | 32100(27600) | 160 | 6.0 | 4 | ∅500 | 4×6000 | 167(17) | 15 | 4×550 | 380 | 12.5 | 2.5 | 220 | 260 |
| DD-37.4/200A | 37400(32200) | 200 | 6.0 | 4 | ∅500 | 4×6000 | 167(17) | 15 | 4×550 | 380 | 13.5 | 2.7 | 220 | 320 |
| DD-37.4/200B | 37400(32200) | 201 | 6.0 | 2 | ∅600 | 2×10000 | 200 | 18 | 2×1100 | 380 | 15.2 | 1.9 | 220 | 356 |
| DD-46.8/250 | 46800(40300) | 256 | 6.0 | 3 | ∅600 | 3×10000 | 200 | 18 | 3×1100 | 380 | 17.6 | 2.2 | 220 | 400 |
| DD-56.2/310 | 56200(48300) | 307 | 6.0 | 3 | ∅600 | 3×10000 | 200 | 18 | 3×1100 | 380 | 20 | 2.5 | 220 | 420 |
| DD-67.0/372 | 67000(57620) | 372 | 6.0 | 3 | ∅600 | 3×12000 | 240 | 20 | 3×1500 | 380 | 23 | 2×2.3 | 220 | 450 |
| DD-81.5/450 | 81500(70090) | 450 | 6.0 | 3 | ∅700 | 3×15000 | 290 | 25 | 3×2200 | 380 | 2703 | 2×2.1 | 220 | 4560 |
| DD-99.6/530 | 99600(85650) | 525 | 6.0 | 3 | ∅700 | 3×15000 | 290 | 25 | 3×2200 | 380 | 31.2 | 2×2.4 | 220 | 620 |
Main features
1) The sheet metal parts of the air cooler series are pressed in
one go by hydraulic press or hydraulic punch, which has excellent
appearance and structural strength.
2) The sheet metal parts are available in three types: aluminum
rolled plate, sprayed plate, and stainless steel plate, which can
be selected according to your needs.
3) The insulated U-shaped electric heating tube is used, and the
defrosting time is short and the effect is excellent when needed.
4) The coil uses thick copper tube, which extends the life of the
aluminum sheet. The aluminum sheet is in close contact with the
high-rise tube and copper tube to maximize the heat transfer
effect.
5) The high-efficiency fan is used, which has large air volume,
long distance, low noise, low power consumption, long life and high
reliability.
Packing details:
Generally speaking, (L:W:H)m is the standard size. Wooden boxes
exported to all countries will be fumigated. If the product is too
large, it will be sealed with plastic and then fixed with steel
wire.
Company Profile:
We are Damai Cold Chain Equipment Co., Ltd. We have more than ten
years of experience in the refrigeration industry. We sell all the
refrigeration equipment on the cold storage, including cold storage
panels, condensers, air coolers, and refrigeration units. All of
these are customized. Our products have been tested by the market
and have achieved the best quality at the most reasonable cost.
FAQ:
Are you a factory or a trading company?
We are a company with our own factory
Which refrigerant do you need?
R404,R507,R22……
Which condenser do you prefer?
We all have different condensers according to needs.
What temperature does your cold storage support?
0℃,-18℃,>-18℃……
What is the power?
We can make the power according to your request
What is your warranty?
1year.
