Advanced Cold Room Evaporator For Optimal Temperature Control In
Industrial Settings Both Side
Product Description:
| Model | Nominal cooling capacity | Cooling area(㎡) | Pitch of fins(㎜) | Fan | Water volume(T/h) | Water inlet tube diameter | Water outlet pipe diameter | Weight(㎏) |
| Number | Diameter | Air volume | Wide pressure | Motor(W) | Voltage(V) |
| DLS-16.7/80 | 16700(14350) | 80 | 4.5 | 2 | ∅500 | 2×6000 | 167 | 2*550 | 380 | 2.1 | 1″ | 2″ | 135 |
| DLS-22.0/105 | 22000(18900) | 105 | 4.5 | 2 | ∅500 | 2×6000 | 167 | 2*550 | 380 | 2.8 | 1″ | 2″ | 175 |
| DLS-25.8/125 | 25800(22200) | 125 | 4.5 | 3 | ∅500 | 3×6000 | 167 | 3*550 | 380 | 3.5 | 1½″ | 3″ | 190 |
| DLS-33.6/160 | 33600(28900) | 160 | 4.5 | 3 | ∅500 | 3×6000 | 167 | 3*550 | 380 | 4.2 | 1½″ | 3″ | 210 |
| DLS-38.7/185 | 38700(33300) | 185 | 4.5 | 4 | ∅500 | 4×6000 | 167 | 4*550 | 380 | 4.9 | 1½″ | 3″ | 250 |
| DLS-44.0/210 | 44000(37850) | 210 | 4.5 | 4 | ∅500 | 4×6000 | 167 | 4*550 | 380 | 5.6 | 1½″ | 3″ | 280 |
| DLS-52.9/260A | 52900(45500) | 256 | 4.5 | 4 | ∅500 | 4×6000 | 167 | 4*550 | 380 | 7.0 | 1½″ | 3″ | 330 |
| DLS-52.9/260B | 52900(45500) | 258 | 4.5 | 2 | ∅600 | 2×10000 | 200 | 2*1100 | 380 | 7.0 | 1½″ | 3″ | 410 |
| DLS-67.2/330 | 67200(57800) | 326 | 4.5 | 3 | ∅600 | 3×10000 | 200 | 3*1100 | 380 | 8.75 | 2″ | 4″ | 480 |
| DLS-83.4/410 | 83400(71700) | 407 | 4.5 | 3 | ∅600 | 3×10000 | 200 | 3*1100 | 380 | 10.85 | 2″ | 4″ | 510 |
| DLS-101.7/500 | 101700(87460) | 496 | 4.5 | 3 | ∅600 | 3×12000 | 240 | 3*1500 | 380 | 13.1 | 2″ | 4″ | 540 |
| DLS-122.0/600 | 122000(104900) | 604 | 4.5 | 3 | ∅700 | 3×18000 | 290 | 3*2200 | 380 | 15.7 | 2″ | 4″ | 620 |
| DLS-142.3/700 | 142300(122370) | 700 | 4.5 | 3 | ∅700 | 3×18000 | 290 | 3*2200 | 380 | 18.5 | 2″ | 4″ | 680 |
Features:
Our product is scientifically structured, highly efficient, and
evenly distributes frost, resulting in lower power and running
costs. Our models match with axial fans that offer strong airflow
over long distances, are power-efficient and have long life cycles.
Our expansion processing technology ensures perfect tightness
between the pipe and fins. Additionally, our product is compatible
with stainless electric heater, offering high insulating property
and efficient defrosting in short amounts of time.
The heat exchanging coil can pass a gas tightness test of up to
2.6MPa air pressure. Our product is made with aluminum and painted
stan board, to meet your different demands, and provide a durable
and long-lasting solution.
Sphere of Application
Our product can be utilized in a variety of settings, such as
industrial cooling, HVAC systems, refrigeration, and more. It is
ideal for use in both commercial and residential settings.
Whether you're looking for high efficiency and energy savings, or
durability and reliability, our product offers the perfect solution
for your needs.
Technical Parameters:
It is essential to consider the nature of the items being stored
while designing a storage facility. Specific temperature ranges are
required to ensure the quality control and preservation of
different types of products.
If you need to store fruits to ripen, it is important to maintain a
temperature of over 25°C. Similarly, for processing items such as
fruits and vegetables, a temperature range of 12°C to 19°C is
suitable.
The storage of dry foods and perishable goods such as fruits and
vegetables requires a temperature range of -5°C to +10°C. Medicine,
cakes, pastries, and chemical materials, on the other hand, require
a temperature range of 0°C to -5°C to stay fresh and useful.
For items such as fish and meat, it is necessary to maintain a
temperature range of -18°C to -25°C to prevent spoilage. For the
storage of ice, an appropriate temperature range of -5°C to -10°C
is required to keep it from melting, while for deep freeze,
low-temperature storage, quick-freeze, and blast freezer, it is
necessary to maintain a temperature range of -25°C to -40°C.
Applications:
There are various types of cold storage facilities that are
available to store different kinds of temperature-sensitive
products. These facilities include the freezer room, blast freezer,
and chiller room, which are used to preserve meat, seafood, fruits,
and vegetables. The freezer room is a facility designed to maintain
freezing temperatures, whereas the blast freezer is a type of
freezer that is equipped with a powerful refrigeration system that
can rapidly freeze the products.
The chiller room is another type of storage unit designed to
maintain cool and dry conditions for products such as fruits,
vegetables, dairy products, and beverages. Apart from these, there
are specialized cold storage facilities like display cold rooms
which are designed for supermarkets and other retail outlets to
showcase products, Logistics cold storages which are designed to
store temperature-sensitive goods during transportation.
Overall, these facilities play a critical role in ensuring the
longevity of perishable products during transit and storage, making
them an essential part of the supply chain for food and other
temperature-sensitive products.
Customization:
Customize your Cold Room Evaporator with DM brand, model number
DM-0006, and place of origin China. This product is CE ISO
certified and has a minimum order quantity of 1, with a price range
of 1000-100000. The packaging details are customizable and the
delivery time is 20 days. Payment terms include TT and L/C, with a
supply ability of 300000/year. Our business type is RD &
Manufacturing Factory, with a series of SDL/SDD. This product
operates at high, medium, and low temperatures, with a long
operating cycle. Its Hs Code is 8418991000.
Cold Room Evaporators are essential for temperature control in
commercial settings. Our Air Cooled Evaporator is designed for
efficient cooling and is ideal for use in Cold Rooms. Our
Commercial Evaporative Air Cooler provides long-lasting cooling
solutions for various settings, including warehouses, supermarkets,
and other commercial spaces.
Support and Services:
- Installation guidance and support
- Troubleshooting assistance for any technical issues
- Regular maintenance and repair services
- Product training and education for end-users and technicians
- Access to technical documentation and manuals
- Warranty and post-warranty support
- Upgrades and replacement parts
Our team of experienced technicians and engineers are dedicated to
ensuring the proper functioning and longevity of your Cold Room
Evaporator product. Contact us for any technical support and
service needs.
Packing and Shipping:
- The Cold Room Evaporator is securely packed in a cardboard box
- The box is then sealed with strong tape to prevent any damage
during shipping
- The Cold Room Evaporator is shipped via a reliable courier service
- Shipping is available to most locations worldwide
- Delivery times may vary depending on the destination
- A tracking number will be provided once the product has been
shipped
FAQ:
Q: Where is this Cold Room Evaporator produced?
A: This product is produced in China.
Q: Does this Cold Room Evaporator have any certifications?
A: Yes, this product has CE and ISO certifications.
Q: What is the minimum order quantity for this Cold Room
Evaporator?
A: The minimum order quantity for this product is 1.
Q: What is the price range of this Cold Room Evaporator?
A: The price range of this product is between 1000-100000.
Q: Can the packaging details for this Cold Room Evaporator be
customized?
A: Yes, the packaging details for this product can be customized.
Q: What is the delivery time for this Cold Room Evaporator?
A: The delivery time for this product is 20 days.
Q: What are the payment terms for this Cold Room Evaporator?
A: The payment terms for this product are TT and L/C.
Q: What is the supply ability for this Cold Room Evaporator?
A: The supply ability for this product is 300000 units per year.
