Industrial Cold Room Evaporator for Temperature Control in Commercial Refrigeration
Product Description:
| Model | Length(L) | Width(W) | Height(H) | Physical size | Water tube (inch) | Connecting tube Φ | |
| Weiaht |
| B | T | H | L | E1 | E2 | E3 | E4 | E5 | F | Iulet(rnm) | Outlet(mm) | Water Inlet(inch) | (kg) |
| UDLS-060B | 1460 | 611 | 889 | 510 | 1150 | 575 | 575 | / | / | 130 | 3 | 16 | 35 | 2001/1/2 | 106 |
| UDDS-040B | 105 |
| UDJS-030B | 104 |
| UDLS-080B | 1710 | 669 | 889 | 560 | 1400 | 700 | 700 | / | / | 130 | 3 | 16 | 35 | 2001/1/2 | 136 |
| UDDS-060B | 134 |
| UDJS-040B | 132 |
| UDLS-105B | 1810 | 719 | 889 | 610 | 1500 | 750 | 750 | / | 1 | 130 | 3 | 16 | 50 | 2001/1/2 | 153 |
| UDDS-080B | 150 |
| UDJS-055B | 147 |
| UDLS-135B | 2260 | 719 | 889 | 610 | 1950 | 650 | 650 | 650 | 1 | 130 | 3 | 22 | 50 | 1-1/2×2 | 194 |
| UDDS-100B | 190 |
| UDJS-070B | 188 |
| UDLS-160B | 2760 | 719 | 889 | 610 | 2450 | 817 | 816 | 817 | / | 130 | 3 | 22 | 50 | 1-1/2×2 | 227 |
| UDDS-120B | 222 |
| UDJS-085B | 217 |
| UDLS-185B | 3010 | 719 | 889 | 610 | 2700 | 675 | 675 | 675 | 675 | 130 | 3 | 25 | 50 | 1-1/2×2 | 258 |
| UDDS-140B | 255 |
| UDJS-100B | 252 |
| UDLS-210B | 2910 | 769 | 889 | 660 | 2600 | 650 | 650 | 650 | 650 | 130 | 3 | 25 | 50 | 1-1/2×2 | 274 |
| UDDS-160B | 267 |
| UDJS-115B | 260 |
| UDLS-260B | 3110 | 769 | 989 | 660 | 2800 | 933 | 934 | 933 | / | 130 | 4 | 25 | 50 | 2×2 | 311 |
| UDDS-200B | 302 |
| UDJS-140B | 295 |
| UDLS-330B | 3010 | 819 | 989 | 710 | 2700 | 675 | 675 | 675 | 675 | 130 | 4 | 25 | 50 | 2×2 | 348 |
| UDDS-250B | 337 |
| UDJS-170B | 330 |
| UDLS-400B | 3010 | 819 | 1086 | 710 | 2700 | 675 | 675 | 675 | 675 | 130 | 4 | 25 | 54 | 2×2 | 388 |
| UDDS-300B | 375 |
| UDJS-210B | 370 |
| UDLS-210BT | 2060 | 1059 | 1008 | 710 | 1750 | 875 | 875 | / | / | 130 | 4 | 25 | 50 | 2 | 282 |
| UDDS-160BT | 275 |
| UDJS-115BT | 268 |
| UDLS-260BT | 2490 | 1059 | 1008 | 710 | 2180 | 1090 | 1090 | / | / | 130 | 4 | 25 | 50 | 2 | 319 |
| UDDS-200BT | 310 |
| UDJS-140BT | 305 |
| UDLS-330BT UDDS-250BT UDJS - 170BT | 3010 | 1059 | 1008 | 710 | 2700 | 900 | 900 | 900 | 1 | 130 | 4 | 25 | 54 | 2×2 | 398 |
| 387 |
| 382 |
| UDLS-400BT | 3010 | 1059 | 1108 | 710 | 2700 | 900 | 900 | 900 | / | 130 | 4 | 25 | 54 | 2×2 | 424 |
| UDDS-300BT | 411 |
| UDJS-210BT | 405 |
| UDLS-500BT | 3010 | 1159 | 1108 | 810 | 2700 | 900 | 900 | 900 | / | 130 | 4 | 25 | 54 | 2×2 | 473 |
| UDDS-370BT | 457 |
| UDJS-250BT | 450 |
| UDLS-600BT | 3210 | 1159 | 1208 | 810 | 2900 | 725 | 725 | 725 | 725 | 130 | 4 | 32 | 67 | 2×2 | 573 |
| UDDS-450BT | 553 |
| UDJS-300BT | 543 |
| UDLS-640BT | 3410 | 1174 | 1208 | 810 | 3100 | 775 | 775 | 775 | 775 | 130 | 4 | 2×25 | 2×54 | 2×2 | 594 |
| UDDS-480BT | 574 |
| UDJS-320BT | 564 |
| UDLS-700BT | 3710 | 1174 | 1208 | 810 | 3400 | 850 | 850 | 850 | 850 | 130 | 4 | 2×25 | 2×54 | 2×2 | 629 |
| UDDS-520BT | 607 |
| UDJS-350BT | 597 |
Features:
The product boasts a scientific structure that enables it to perform with high efficiency and frost evenly. This not only saves power, but it also reduces running costs, making it an economical choice.
In addition, it matches well with axial fan quiet models that offer strong air flow in long shot ranges, making it power-saving with a long life cycle.
After expansion processing, it leads to perfect tightness between the pipe and fin.
The product also matches well with stainless electric heaters that have high insulating properties and defrost efficiently in a short time.
The heat exchanging coil passes a gas tightness test up to 2.6 MPa air pressure, ensuring quality and durability.
Not only that, but the product also features aluminum and painted stan board which is designed to meet your different demands, ensuring versatility in its sphere of application.
Technical Parameters:
The appropriate temperature range for different types of storage can vary based on the nature of the items being stored. When it comes to fruit ripening, it is recommended to maintain temperatures above 25°C. For processing rooms, the ideal temperature range is between 12°C to 19°C to ensure that food items can be safely processed.
If you are storing fruit, vegetables, or dry foods, it is recommended to maintain a temperature range between -5°C to +10°C. However, if you are storing medicines, cakes, pastries, or chemical materials, it is important to maintain temperatures between 0°C to -5°C to ensure they stay fresh and effective.
For ice storage rooms, the recommended temperature range is between -5°C to -10°C. If you need to store fish or meat, it is recommended to keep the temperature around -18°C to -25°C to prevent bacterial growth and ensure freshness.
If you require low-temperature storage, a deep freezer, a quick-freeze unit, or a blast freezer, the temperature range must be maintained between -25°C to -40°C. By following these guidelines, you can maintain the quality and freshness of your stored items.
Applications:
There are various types of cold storage facilities available for different purposes. For instance, a freezer room is designed specifically for freezing and storing food items such as meat, seafood, and vegetables. The blast freezer, on the other hand, is used to rapidly freeze food products to preserve their quality and freshness.
Another type of cold storage is the chiller room, which is kept at a temperature slightly above freezing point to keep perishable items such as dairy products and fresh meat fresh for a longer duration. Meanwhile, the display cold room is used to showcase frozen or chilled items in a retail environment.
Cold storage facilities are not only used in the food industry, but also in logistics. Logistics cold storage facilities are used to keep temperature-sensitive goods such as medicines and vaccines at the appropriate temperature in transit, ensuring that they arrive at their destination in good condition.
In summary, whether you need a freezer room, blast freezer, cold storage, meat cold, fruit and vegetable storage, seafood storage, display cold room, chiller room, or logistics cold storage, there is a facility designed to meet your specific needs.
Support and Services:
We offer regular training and educational materials to ensure that you and your team are equipped with the knowledge to operate and maintain your Cold Room Evaporator effectively. In addition, we provide customized solutions to meet your specific needs and requirements.
For every machine, it will be tested before shipment, and our products have undergone market inspection, ensuring absolute quality assurance.
Our commitment to quality and customer satisfaction means that we are always available to answer any questions or concerns you may have about your Cold Room Evaporator. Contact us today to learn more about our product technical support and services.
Packing and Shipping:
Product Name: Cold Room Evaporator
Product Description: This Cold Room Evaporator is designed to maintain a consistent temperature in cold rooms. It is made of high-quality materials and has a durable construction.
Packaging: The Cold Room Evaporator is carefully packaged to ensure safe delivery. It is packed in a sturdy box with foam inserts to prevent any damage during shipping.
FAQ:
Q: Where is this product manufactured?
A: This product is manufactured in China.
Q: What certifications does this product have?
A: This product is certified with CE and ISO.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 1.
Q: What are the packaging details for this product?
A: The packaging details for this product can be customized.
Q: How long is the delivery time?
A: The delivery time for this product is 20 days.
Q: What are the payment terms for this product?
A: The payment terms for this product are TT and L/C.
Q: What is the supply ability for this product?
A: The supply ability for this product is 300000 per year.
Q:Are you a manufacturer or a trader?
A:We have our own factory and we work in the factory
