Continuous Quick-freezing Work with Belt Speed 0-10m/min Quick
Tunnel Freezer
Product Description:
The unique working principle and design features of the
quick-freezing tunnel make it an efficient and uniform cooling
equipment. It is extensively used in the production of quick-frozen
foods such as vegetables, meat, aquatic products, pastries, fruits,
prepared foods and ice cream.
Applications:
Our company provides high-quality rapid cooling equipment that
caters to the needs of food, chemical, and industrial sectors. Our
equipment is designed to cool various objects quickly and
efficiently, ensuring that it meets the high standards of our
clients.
Suitable for Various Objects
| Quick Freezing Tunnel Specifications |
| Model | Dimensions | Belt Size | Freezing Time | Power | Weight |
| (L*W*H) | (L*W) | (min) | (KW) | (KG) |
| AS-6-0.8 | 6.5X1.72X2.1 | 6X0.8 | 3-20min | 6KW | 3000kg |
| AS-9-0.8 | 9.5X1.72X2.1 | 9X0.8 | 3-40min | 8KW | 3500kg |
| AS-14-0.8 | 14.5X1.72X2.1 | 14X0.8 | 3-65min | 12KW | 5000kg |
|
| AS-6-1.25 | 6.5X2.17X2.1 | 6X1.25 | 3-20min | 7KW | 3500kg |
| AS-9-1.25 | 9.5X2.17X2.1 | 9X1.25 | 3-40min | 10KW | 4500kg |
| AS-14-1.25 | 14.5X2.17X2.1 | 14X1.25 | 3-65min | 16KW | 6500kg |
| General technical parameters |
| Height of feed port from ground | 900mm |
| Height of frozen product | 150mm |
| 380V |
| Exhaust pipe size | 300mm |
Customization:
DM offers product customization services for the DM-SDSD rapid
tunnel cooler, also known as the expeditious blast freezer or the
instantaneous tunnel icebox. Made in China, this freezer uses a
direct expansion cooling system and has a belt speed of 0-10m/min.
It has a temperature range of -40℃ to -18℃, making it perfect for
individual quick freezing. Our machinery test report is provided
for quality assurance. Contact us for personalized options to meet
your specific needs.
Support and Services:
The Quick Tunnel Freezer is designed to quickly freeze products
such as fruits, vegetables, meat, poultry, and seafood. Our product
technical support and services include:
- Installation and setup assistance
- Training for proper usage and maintenance
- 24/7 technical support
- Regular maintenance and repair services
- Upgrades and modifications to improve performance
We are committed to ensuring that our customers receive the best
possible support and services for their Quick Tunnel Freezer.
FAQ:
Q: Where is the Quick Tunnel Freezer manufactured?
A: The Quick Tunnel Freezer is manufactured in China.
Q: What is the freezing capacity of the Quick Tunnel Freezer?
A: The freezing capacity of the Quick Tunnel Freezer varies
depending on the product being frozen and the temperature needed.
Please consult the product manual for specific details.
Q: Is the Quick Tunnel Freezer easy to clean?
A: Yes, the Quick Tunnel Freezer is designed to be easy to clean
with removable parts and a smooth surface. Please consult the
product manual for specific cleaning instructions.
