Product Description:
Parameter Description
Product Name: Polyurethane Sandwich Composite Panel/ Cold storage
panels
Thickness: 100/120/150/200mm customizable
Density: ≥38(kg/m3)
Heat Transfer Coefficient: 0.45W/(m2.k)
Thermal Conductivity: 0.024W/(m.k)
Oxygen Index: 28%
Combustion Performance: EN13501-B s2d0
Main Application Occasions: cold room panel
Sheet name: Polyurethane wall panel
Specifications:
Effective lap (mm): 1000mm
Plate thickness (mm): 50/75/100/120/150/200
Color plate thickness (mm): 0.4-0.8
Optional panels: Color coated steel, stainless steel, galvanized
steel
Regular colors: White gray, large wall gray, dark blue
Plate effect: flat, embossed, small ripples, pressure ribs
Features:
Surface optional materials and advantages
Advantages:
With good thermal insulation performance, high compressive
strength, flexible combination, easy installation, etc.
Field of employment:
Cold chain logistics, biomedicine, chemical industry, food, cold
storage, frozen storage, fruits and vegetables, edible fungi, meat
processing, etc
- Thickness of plating (mm): 150, 180, 200
- Fireproof performance: B1, B2 level
Technical Parameters:
Product Details
Product Name: Polyurethane Sandwich Composite Panel/ Cold storage panels
Thickness: 100/120/150/200mm, customizable
Density: ≥38(kg/m3)
Heat Transfer Coefficient: 0.45W/(m2.k)
Thermal Conductivity: 0.024W/(m.k)
Oxygen Index: 28%
Combustion Performance: EN13501-B s2d0
Main Application Occasions: cold room panel
Sheet name: Polyurethane wall panel
Effective lap (mm): 1000mm
Plate thickness (mm): 50/75/100/120/150/200
Color plate thickness (mm): 0.4-0.8
Optional panels: Color coated steel, stainless steel, galvanized steel
Regular colors: White gray, large wall gray, dark blue
Plate effect: flat, embossed, small ripples, pressure ribs
Applications:
Cold chain logistics is crucial in various industries such as
biomedicine, the chemical industry, and food. It plays a vital role
in the transportation and storage of goods from different sectors
to ensure their quality and safety. Industries like cold storage,
frozen storage, fruits and vegetables, edible fungi, and meat
processing heavily rely on the effective cold chain logistics
system to maintain the integrity of their products.
In the biomedicine sector, cold chain logistics is essential for
preserving the efficacy of medicines and vaccines, as
temperature-controlled environments are necessary to prevent
degradation. Similarly, the chemical industry requires precise
temperature control during transportation and storage to maintain
the integrity of chemical products. Additionally, in the food
industry, cold chain logistics is paramount in preserving the
freshness and quality of perishable goods from farm to table.
Customization:
Product Customization Services for Refrigerated Cold Room Panels
Brand Name: DM
Model Number: DM-LKB-001
Place Of Origin: Made In China
Delivery Time: 30 Work Days
Payment Terms: T/T
Supply Ability: 1000000㎡/year
Refrigeration Parts: Danfoss Castel Emerson
Pu Density: 38kgs
Drive: By Gear
Insulation Material: PU/PIR
Application: Cold Storage, Freezer Room, Refrigerated Warehouse,
Etc.
Product Attributes: Cool room Insulation Panels, Freezer Panel
Systems
Support and Services:
The Cold Room Panel product comes with comprehensive Product
Technical Support and Services to assist customers with any
inquiries or issues they may encounter. Our dedicated team of
experts is available to provide guidance on installation,
maintenance, troubleshooting, and other technical aspects of the
product. Additionally, we offer training sessions and resources to
ensure that customers can maximize the performance and longevity of
their Cold Room Panels.
